Memory slots : 16 DIMM slots per socket, one socket only
Memory type : HPE DDR5 SmartMemory
Memory protection features : HPE Fast Fault Tolerant Memory
Advanced ECC Memory
Online Spare Memory
Mirrored Memory
Drive supported : Up to 4 LFF SAS/SATA HDDs or SSDs.
Up to 8+2 SFF SAS/SATA HDDs or SATA/SAS/NVMe U.2 or U.3 SDDs, depending on model.
Optional embedded 2 M.2 Boot SSD.
Optional RAID 1 NVMe M.2 Boot device (Internal or external accessible from rear wall with 2x NVMe M.2 incorporated).
Infrastructure management : Included – HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download).
Optional – HPE iLO Advanced, and HPE OneView Advanced.
System fan features : Standard Fan Kit or High Performance Fan Kit, depending on model.
Power supply type : HPE 500W Flex Slot Platinum Hot Plug Power Supply, HPE 800W Flex Slot Platinum Hot Plug Power Supply, HPE 1000W Flex Slot Titanium Power Supply, HPE 1600W Flex slot Platinum Hot Plug Power Supply, depending on model.
Expansion slots : Maximum, 2 PCIe Gen5 & 1 OCP 3.0 PCIe Gen5, for detail descriptions please refer to the QuickSpecs.
Network controller : Wide range of speeds, cabling, chipsets and form factors (PCIe stand-up adapter and OCP3.0). Please refer to the QuickSpecs for network card choices.
Storage controller : Included – Embedded SATA controller (AHCI or Intel SATA software RAID controller)
Optional – HPE Smart Array Gen11 Storage Controller in Variety of protocols -including NVMe-, port count, array utilities, and form factors (PCIe stand-up adapter and OCP3.0). Please refer to the QuickSpecs for storage controllers selection.
Warranty : 3/3/3: Server Warranty includes three years of parts, three years of labor, and three years of onsite support coverage.
Processor number : 1
Processor speed : 3.7 GHz maximum, depending on processor.
Optical drive type : Optional HPE 9.5mm SATA DVD-RW Optical Drive, HPE Mobile USB DVD-RW Drive
Security : UEFI Secure Boot and Secure Start support.
Intel® Software Guard Extensions (SGX) support.
Immutable Silicon Root of Trust.
Optional Trusted Supply Chain, iLO Security modes, TPM, Chassis Intrusion detection and Bezel Locking kits.
DIMM capacity : 16 GB to 256 GB
