Temukan performa tinggi HPE ProLiant DL560 Gen11 bersama Synnex Metrodata Indonesia

Processor type Intel®

Processor family 4th Generation Intel® Xeon® Scalable Processors

Processor core available 8 to 60 core, depending on processor.

Processor cache 22.5 MB to 112.5 MB L3, depending on processor.

Maximum memory 16 TB with 256 GB DDR5

Memory slots 64

Memory type HPE DDR5 SmartMemory

Memory protection features RAS – Advanced ECC, online spare, mirroring, combined channel (lockstep) functionality, and HPE Fast Fault Tolerant Memory (ADDDC); Intel Optane Persistent Memory

Drive supported 8, 16, or 24 SFF SAS/SATA/SSD/NVMe, depending on configuration.

Infrastructure management HPE iLO Standard with intelligent provisioning (embedded), HPE OneView Standard (requires download) (standard) HPE iLO Advanced, HPE OneView Advanced (optional, requires licenses), and HPE GreenLake COM.

System fan features Liquid cooling solution, Hot-plug redundant fans, Performance Fan Kit or High Performance Fan Kit, depending on model.

Power supply type 800W, 1000W, 1600W or 2200W Dual hot-plug redundant 1+1 redundant or 2+2 redundant or 3+1 redundant
and 4+0 redundant, depending on model.

Expansion slots Up to 6 PCIe Gen5, and 2 OCP 3.0, for detailed descriptions reference the QuickSpecs.

Network controller 1 Gb, 10 Gb, 10/25 Gb, 100 Gb, or 200 Gb, in PCIe adapter or OCP 3.0 form factor; for detailed descriptions reference the QuickSpecs.

Storage controller HPE Smart Array E208e-p SR Gen10 (8 External Lanes/No Cache) 12G SAS PCIe Plug-in Controller,
HPE SR416i-o Gen11 x16 Lanes 8GB Cache OCP SPDM Storage Controller,
HPE SR932i-p Gen11 x32 Lanes 8GB Wide Cache PCI SPDM Plug-in Storage Controller,
HPE MR416i-p Gen11 x16 Lanes 8GB Cache PCI SPDM Plug-in Storage Controller,
HPE MR416i-o Gen11 x16 Lanes 8GB Cache OCP SPDM Storage Controller,
HPE SR308i-p Gen11 x8 Lanes 2GB Cache PCI Plug-in Storage Controller,
HPE SR308i-o Gen11 x8 Lanes 2GB Cache OCP Storage Controller,
HPE MR408i-o Gen11 x8 Lanes 4GB Cache OCP SPDM Storage Controller,
HPE MR216i-p Gen11 x16 Lanes without Cache PCI SPDM Plug-in Storage Controller,
HPE MR216i-o Gen11 x16 Lanes without Cache OCP SPDM Storage Controller, for detailed descriptions reference the QuickSpecs.

Warranty 3/3/3: Server Warranty includes three years of parts, three years of labor, and three years of onsite support coverage.

Processor number 2 or 4

Processor speed 3.7 GHz maximum, depending on processor.

Optical drive type Optional DVD-ROM Optional via Universal Media Bay External support only.

Security HPE TPM 2.0 standard on motherboard. Optional locking Bezel Kit, Intrusion Detection Kit.

DIMM capacity 16 GB to 256 GB

• Powered by the 4th Generation Intel® Xeon® Scalable Processors with modern technology that support up to 60 cores at 350W and 16 DIMMs for DDR5 memory at speeds up to 4800 MHz.
• Support for up to 16 TB total DDR5 memory with 8 DIMM channels per processor that deliver increased performance and lower power requirements.
• Support for PCIe Gen5, resulting in improved bandwidth, advanced data transfer rates, and higher network speeds from the PCIe Gen5 serial expansion bus.
• Includes the HPE Integrated Lights-Out 6 (iLO 6) server management software that enables you to securely configure, monitor, and update your HPE ProLiant Gen11 servers seamlessly, from anywhere.
• Supports hot-pluggable, high-availability RAID M.2 boot options.
• Supports up to six single wide (SW) or two double wide (DW) GPUs to accelerate graphic-intense workloads.

• Intuitive Cloud Operating Experience: Simple, Self-service, and Automated

• Trusted Security by Design: Uncompromising, Fundamental, and Protected

• Customized Performance for your Workloads: Accelerated, Open, and Efficient

• Available in an As-a-Service Experience
